Description
Brand - FAG
Item Number - S1BC-600-FL FAG
Category - Split Cylindrical Roller Bearing Housing
Shaft Diameter (d) inch - 6
Cartridge Assembly Float Bearing - S1BC-600-FL
Cartridge Assembly Held Bearing - S1BC-600-HD
Length Through Bore (G) inch - 6.75
Outside Diameter Cartridge (L) inch - 11.625
Grease Capacity (lbs) - 2
Cartridge - S1C-600
Weight (kg) - 43.998424
Bearing Float - S1B-600-FL
Bearing Held - S1B-600-HD
Bearing Weight (kg) - 16.8282632
Basic Dynamic Radial Load Rating (Cr) lbs - 87637
Basic Static Radial Load Rating (C0r) lbs - 141821
Basic Dynamic Axial Load Rating (Ca) lbs - 762
Maximum Limiting Speed (rpm) - 1670
Outside Diameter Bearing (Do) inch - 10
Width Inner Ring (Co) inch - 3.875
Width Outer Ring (Bo) inch - 2.188
Housing Group - 600 Grp
