Description
Brand - IKO
Item Number - RNA 4928UU IKO
Also Known As - RNA4928UU
Category - Machined Type Needle Roller Bearing with Seal without Inner Ring
Seal - Two Seals
Shaft Diameter (mm) - 160
Boundary Dimension (Fw) mm - 160
Outer Diameter (D) mm - 190
Boundary Dimension (C) mm - 50
Minimum Boundary Dimension (rs) mm - 1.5
Maximum Standard Mounting Dimension (Da) mm - 182
Basic Dynamic Load Rating (C) N - 214000
Basic Static Load Rating (C0) N - 549000
Allowable Rotational Speed (min-1) - 1200
Weight (kg) - 2.51
Bearing With One Seal - RNA 4928U
** Images are for representation purposes only
