Description
Brand - NILOS
Item Number - QJ 207 JV NILOS
Category - NILOS-RING for Four Point Contact Ball Bearing
Principal Dimensions & Load Ratings (Metric) :
Inner Diameter (i) - 43 mm
Dimension (c) - 56 mm
Outer Diamter (D) - 72 mm
Width (h) - 2.5 mm
Material Thickness (s) - 0.3 mm
Description of Compatible Bearing (QJ 2 Series) :
Bearing Part Number - QJ 207
Bearing Type - Double Row Self-Aligning Ball Bearing
Inner Diameter (d) - 35 mm
Outer Diameter (D) - 72 mm
Width (B) - 17 mm
♦ ♦ Images are for representation purposes only
Item Number - QJ 207 JV NILOS
Category - NILOS-RING for Four Point Contact Ball Bearing
Principal Dimensions & Load Ratings (Metric) :
Inner Diameter (i) - 43 mm
Dimension (c) - 56 mm
Outer Diamter (D) - 72 mm
Width (h) - 2.5 mm
Material Thickness (s) - 0.3 mm
Description of Compatible Bearing (QJ 2 Series) :
Bearing Part Number - QJ 207
Bearing Type - Double Row Self-Aligning Ball Bearing
Inner Diameter (d) - 35 mm
Outer Diameter (D) - 72 mm
Width (B) - 17 mm
♦ ♦ Images are for representation purposes only
