Description
Brand - BECO
Category - Housing in Stainless Steel (not Magnetic)
Item Number - PA 209 SS BECO
Diameter (D) mm - 85
Maximum Dimension (L) mm - 120
Dimension (J) mm - 90
Maximum Dimension (A) mm - 60
Maximum Dimension (H) mm - 108
Maximum Dimension (H1) mm - 13
Dimension (H2) mm - 54.2
Dimension (N) mm - M14
Dimension (F) mm - 25
* Weight (kg) - 1.3
----------------------------------------------
Housing + Bearing = Bearing Unit
----------------------------------------------
PA 209 SS + UC 209 BHTS ZZ C4 200° = UCPA 209 BHTS ZZ C4 200°
PA 209 SS + UC 209 BHTS 2RS VT 250°-280° = UCPA 209 BHTS 2RS VT 250°-280°
PA 209 SS + UC 209 BHTS ZZ 280° = UCPA 209 BHTS ZZ 280°
PA 209 SS + UC 209 BHTS ZZ 350° Beco Plus = UCPA 209 BHTS ZZ 350° Beco Plus
PA 209 SS + UC 209 BHTS ZZ GR CG 350° = UCPA 209 BHTS ZZ GR CG 350°
PA 209 SS + UC 209 BSS 2RS NSF H1 = UCPA 209 BSS 2RS NSF H1
Note
* Weight for housings is indicative. The production is made from Stainless steel Casting and weight depends from the condition of the moulding
** Images are for representation purposes only
