PA 207 SS BECO


Country Of Origin: ITALY
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - BECO
Category - Housing in Stainless Steel (not Magnetic)
Item Number - PA 207 SS BECO
Diameter (D) mm - 72
Maximum Dimension (L) mm - 110
Dimension (J) mm - 80
Maximum Dimension (A) mm - 55
Maximum Dimension (H) mm - 95
Maximum Dimension (H1) mm - 13
Dimension (H2) mm - 47.6
Dimension (N) mm - M14
Dimension (F) mm - 20
* Weight (kg) - 0.92

----------------------------------------------
Housing + Bearing = Bearing Unit
----------------------------------------------
PA 207 SS + UC 207 BHTS ZZ C4 200° = UCPA 207 BHTS ZZ C4 200°
PA 207 SS + UC 207 BHTS 2RS VT 250°-280° = UCPA 207 BHTS 2RS VT 250°-280°
PA 207 SS + UC 207 BHTS ZZ 280° = UCPA 207 BHTS ZZ 280°
PA 207 SS + UC 207 BHTS ZZ 350° Beco Plus = UCPA 207 BHTS ZZ 350° Beco Plus
PA 207 SS + UC 207 BHTS ZZ GR CG 350° = UCPA 207 BHTS ZZ GR CG 350°
PA 207 SS + UC 207 BSS 2RS NSF H1 = UCPA 207 BSS 2RS NSF H1

Note

* Weight for housings is indicative. The production is made from Stainless steel Casting and weight depends from the condition of the moulding

** Images are for representation purposes only
