Description
Brand - BECO
Category - Housing in Stainless Steel (not Magnetic)
Item Number - PA 206 SS BECO
Diameter (D) mm - 62
Maximum Dimension (L) mm - 94
Dimension (J) mm - 66
Maximum Dimension (A) mm - 50
Maximum Dimension (H) mm - 84
Maximum Dimension (H1) mm - 13
Dimension (H2) mm - 42.9
Dimension (N) mm - M14
Dimension (F) mm - 18
* Weight (kg) - 0.68
----------------------------------------------
Housing + Bearing = Bearing Unit
----------------------------------------------
PA 206 SS + UC 206 BHTS ZZ C4 200° = UCPA 206 BHTS ZZ C4 200°
PA 206 SS + UC 206 BHTS 2RS VT 250°-280° = UCPA 206 BHTS 2RS VT 250°-280°
PA 206 SS + UC 206 BHTS ZZ 280° = UCPA 206 BHTS ZZ 280°
PA 206 SS + UC 206 BHTS ZZ 350° Beco Plus = UCPA 206 BHTS ZZ 350° Beco Plus
PA 206 SS + UC 206 BHTS ZZ GR CG 350° = UCPA 206 BHTS ZZ GR CG 350°
PA 206 SS + UC 206 BSS 2RS NSF H1 = UCPA 206 BSS 2RS NSF H1
Note
* Weight for housings is indicative. The production is made from Stainless steel Casting and weight depends from the condition of the moulding
** Images are for representation purposes only
