PA 204 SS BECO

Brand - BECO
Category - Housing in Stainless Steel (not Magnetic)
Item Number - PA 204 SS BECO
Diameter (D) mm - 47
Maximum Dimension (L) mm - 76
Dimension (J) mm - 52
Maximum Dimension (A) mm - 40
Maximum Dimension (H) mm - 62
Maximum Dimension (H1) mm - 11
Dimension (H2) mm - 30.2
Dimension (N) mm - M10
Dimension (F) mm - 13
* Weight (kg) - 0.41

----------------------------------------------
Housing + Bearing = Bearing Unit
----------------------------------------------
PA 204 SS + UC 201 BHTS ZZ C4 200° = UCPA 201 BHTS ZZ C4 200°
PA 204 SS + UC 202 BHTS ZZ C4 200° = UCPA 202 BHTS ZZ C4 200°
PA 204 SS + UC 203 BHTS ZZ C4 200° = UCPA 203 BHTS ZZ C4 200°
PA 204 SS + UC 204 BHTS ZZ C4 200° = UCPA 204 BHTS ZZ C4 200°
PA 204 SS + UC 201 BHTS 2RS VT 250°-280° = UCPA 201 BHTS 2RS VT 250°-280°
PA 204 SS + UC 202 BHTS 2RS VT 250°-280° = UCPA 202 BHTS 2RS VT 250°-280°
PA 204 SS + UC 203 BHTS 2RS VT 250°-280° = UCPA 203 BHTS 2RS VT 250°-280°
PA 204 SS + UC 204 BHTS 2RS VT 250°-280° = UCPA 204 BHTS 2RS VT 250°-280°
PA 204 SS + UC 201 BHTS ZZ 280° = UCPA 201 BHTS ZZ 280°
PA 204 SS + UC 202 BHTS ZZ 280° = UCPA 202 BHTS ZZ 280°
PA 204 SS + UC 203 BHTS ZZ 280° = UCPA 203 BHTS ZZ 280°
PA 204 SS + UC 204 BHTS ZZ 280° = UCPA 204 BHTS ZZ 280°
PA 204 SS + UC 201 BHTS ZZ 350° Beco Plus = UCPA 201 BHTS ZZ 350° Beco Plus
PA 204 SS + UC 202 BHTS ZZ 350° Beco Plus = UCPA 202 BHTS ZZ 350° Beco Plus
PA 204 SS + UC 203 BHTS ZZ 350° Beco Plus = UCPA 203 BHTS ZZ 350° Beco Plus
PA 204 SS + UC 204 BHTS ZZ 350° Beco Plus = UCPA 204 BHTS ZZ 350° Beco Plus
PA 204 SS + UC 201 BHTS ZZ GR CG 350° = UCPA 201 BHTS ZZ GR CG 350°
PA 204 SS + UC 202 BHTS ZZ GR CG 350° = UCPA 202 BHTS ZZ GR CG 350°
PA 204 SS + UC 203 BHTS ZZ GR CG 350° = UCPA 203 BHTS ZZ GR CG 350°
PA 204 SS + UC 204 BHTS ZZ GR CG 350° = UCPA 204 BHTS ZZ GR CG 350°
PA 204 SS + UC 201 BSS 2RS NSF H1 = UCPA 201 BSS 2RS NSF H1
PA 204 SS + UC 202 BSS 2RS NSF H1 = UCPA 202 BSS 2RS NSF H1
PA 204 SS + UC 203 BSS 2RS NSF H1 = UCPA 203 BSS 2RS NSF H1
PA 204 SS + UC 204 BSS 2RS NSF H1 = UCPA 204 BSS 2RS NSF H1

Note

* Weight for housings is indicative. The production is made from Stainless steel Casting and weight depends from the condition of the moulding

** Images are for representation purposes only
