Description
Brand - BECO
Item Number - P 213 SS BECO
Category - Housing in Stainless Steel (not Magnetic)
Diameter (D) mm - 120
Maximum Dimension (L) mm - 268
Dimension (J) mm - 203
Maximum Dimension (A) mm - 73
Dimension (H) mm - 150
Maximum Dimension (H1) mm - 34
Dimension (H2) mm - 76.2
Dimension (N) mm - 22.8 ± 1.8
Dimension (N1) mm - 24
* Weight (kg) - 2.65
----------------------------------------------
Housing + Bearing = Bearing Unit
----------------------------------------------
P 213 SS + UC 213 BHTS ZZ C4 200° = UCP 213 BHTS ZZ C4 200°
P 213 SS + UC 213 BHTS 2RS VT 250°-280° = UCP 213 BHTS 2RS VT 250°-280°
P 213 SS + UC 213 BHTS ZZ 280° = UCP 213 BHTS ZZ 280°
P 213 SS + UC 213 BHTS ZZ 350° Beco Plus = UCP 213 BHTS ZZ 350° Beco Plus
P 213 SS + UC 213 BHTS ZZ GR CG 350° = UCP 213 BHTS ZZ GR CG 350°
P 213 SS + UC 213 BSS 2RS NSF H1 = UCP 213 BSS 2RS NSF H1
Note
* Weight for housings is indicative. The production is made from Stainless steel Casting and weight depends from the condition of the moulding
** Images are for representation purposes only
