Description
Brand - OAV
Item Number - OAVF50L100 OAV
Category - Flat Rectangular Air Bearing
Housing Material/Finish - 7075 Aircraft Quality Aluminum/ Mil Spec Hard Anodize
Porous Material - Carbon
Imperial :
Minimum Input Pressure (psi) - 40
Maximum Input Pressure (psi) - 100
Ideal Load (lbs) - 266
Stiffness (lbs/μin) - 0.67
Flatness (inch) - 0.00002
Flow (SCFH) - 4.8
Metric :
Size (mm) - 50 x 100
Ideal Load (N) - 1184
Pressure Port Threads - M5 x 0.8
Stiffness (N/μ) - 116.51
Flow (NLPM) - 2.3
Fly Height (μ) - 5
Bearing Height (mm) - 25
Bearing Weight (kg) - 0.295
Flatness (mm) - 0.0005
** Images are for representation purposes only
