Description
Brand - OAV
Item Number - OAVF100L200 OAV
Category - Flat Rectangular Air Bearing
Housing Material/Finish - 7075 Aircraft Quality Aluminum/ Mil Spec Hard Anodize
Porous Material - Carbon
Imperial :
Minimum Input Pressure (psi) - 40
Maximum Input Pressure (psi) - 100
Ideal Load (lbs) - 1154
Stiffness (lbs/μin) - 2.89
Flatness (inch) - 0.00002
Flow (SCFH) - 9.6
Metric :
Size (mm) - 100 x 200
Ideal Load (N) - 5136
Pressure Port Threads - M5 x 0.8
Stiffness (N/μ) - 505.44
Flow (NLPM) - 4.5
Fly Height (μ) - 5
Bearing Height (mm) - 39
Bearing Weight (kg) - 1.877
Flatness (mm) - 0.0005
** Images are for representation purposes only
