Description
Brand - FAG
Item Number - NU1038.C2 FAG
Category - Cylindrical Roller Bearing Single Row
Inner (d) MM - 190
Outer (D) MM - 290
Width (B) MM - 46
Inner (d) Inch - 7.4803
Outer (D) Inch - 11.4173
Width (B) Inch - 1.811
Weight (kg) - 11.2
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - S - Steel or Standard Cage
External Modification - No External Modification
Radial Internal Play - C2 Internal Play (Less than Cn)
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
