Description
Brand - NADELLA
Item Number - NTVZ84-17H-1490-D NADELLA
Category - Hardened Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Length (L) - 1490 mm
Extension (E) - 1440 mm
Load Capacity for Pair of Rails (Cy) - 2749 N
Dynamic Load for Lifetime calculation (Cdyn) - 3090 N
Weight - 10.33 kg
Description of Suffixes and Prefixes:
NTVZ - Full extension telescopic rails
D - Allows Stroke in Double Direction
♦♦ Images are for representation purposes only
