Description
Brand - NADELLA
Item Number - NTVZ84-17H-1010-D NADELLA
Category - Hardened Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Length (L) - 1010 mm
Extension (E) - 960 mm
Load Capacity for Pair of Rails (Cy) - 3793 N
Dynamic Load for Lifetime calculation (Cdyn) - 4964 N
Weight - 7 kg
Description of Suffixes and Prefixes:
NTVZ - Full extension telescopic rails
D - Allows Stroke in Double Direction
♦♦ Images are for representation purposes only
