Description
Brand - NADELLA
Item Number - NTVZ120-28H-1570-D NADELLA
Category - Hardened Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Length (L) - 1570 mm
Extension (E) - 1514 mm
Load Capacity for Pair of Rails (Cy) - 6441 N
Dynamic Load for Lifetime calculation (Cdyn) - 10359 N
Weight - 25.36 kg
Description of Suffixes and Prefixes:
NTVZ - Full extension telescopic rails
D - Allows Stroke in Double Direction
♦♦ Images are for representation purposes only
