Description
Brand - NADELLA
Item Number - NTV60-26-900 NADELLA
Category - Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (C) - 325 mm
Length (L) - 900 mm
Extension (E) - 900 mm
Load Capacity for Pair of Rails (Cy) - 2400 N
Load Capacity for Pair of Rails (Cz) - 1200 N
Net Weight - 4.5 kg
Material - Zinc-Plated Steel
Description of Prefix:
NTV - Telescopic rails full extension
♦♦ Images are for representation purposes only
Item Number - NTV60-26-900 NADELLA
Category - Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (C) - 325 mm
Length (L) - 900 mm
Extension (E) - 900 mm
Load Capacity for Pair of Rails (Cy) - 2400 N
Load Capacity for Pair of Rails (Cz) - 1200 N
Net Weight - 4.5 kg
Material - Zinc-Plated Steel
Description of Prefix:
NTV - Telescopic rails full extension
♦♦ Images are for representation purposes only
