Description
Brand - NADELLA
Item Number - NTV60-26-1000 NADELLA
Category - Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (C) - 375 mm
Length (L) - 1000 mm
Extension (E) - 1000 mm
Load Capacity for Pair of Rails (Cy) - 2250 N
Load Capacity for Pair of Rails (Cz) - 1125 N
Net Weight - 5.1 kg
Material - Zinc-Plated Steel
Description of Prefix:
NTV - Telescopic rails full extension
♦♦ Images are for representation purposes only
