Description
Brand - NADELLA
Item Number - NTU72-47.5DC-800 NADELLA
Category - Telescopic Rail Over Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (C) - 275 mm
Length (L) - 800 mm
Extension (E) - 1200 mm
Maximum Load Per pair - 2400 N
Net Weight - 13.6 kg
Description of Suffixes and Prefixes:
NTU - Telescopic rails over extension
DC - Back-to-Back Assembly
Other salient points to be noted:
• Material - Zinc-Plated Steel
♦♦ Images are for representation purposes only
Item Number - NTU72-47.5DC-800 NADELLA
Category - Telescopic Rail Over Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (C) - 275 mm
Length (L) - 800 mm
Extension (E) - 1200 mm
Maximum Load Per pair - 2400 N
Net Weight - 13.6 kg
Description of Suffixes and Prefixes:
NTU - Telescopic rails over extension
DC - Back-to-Back Assembly
Other salient points to be noted:
• Material - Zinc-Plated Steel
♦♦ Images are for representation purposes only
