Description
Brand - NADELLA
Item Number - NTSU80-43-950 NADELLA
Category - Telescopic Rail Over Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (B) - 550 mm
Length (L) - 950 mm
Extension (E) - 1425 mm
Maximum Load Per pair - 2700 N
Net Weight - 17.9 kg
Description of Prefix:
NTSU - Telescopic rails over extension
Other salient points to be noted:
• Material - Zinc-Plated Steel
• Availble on request - Aluminum, AISI 304 or 316 stainless steel
♦♦ Images are for representation purposes only
Item Number - NTSU80-43-950 NADELLA
Category - Telescopic Rail Over Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (B) - 550 mm
Length (L) - 950 mm
Extension (E) - 1425 mm
Maximum Load Per pair - 2700 N
Net Weight - 17.9 kg
Description of Prefix:
NTSU - Telescopic rails over extension
Other salient points to be noted:
• Material - Zinc-Plated Steel
• Availble on request - Aluminum, AISI 304 or 316 stainless steel
♦♦ Images are for representation purposes only
