Description
Brand - NADELLA
Item Number - NTS63-58H-930-VRM NADELLA
Category - Hardened Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Length (L) - 930 mm
Extension (E) - 922 mm
Load Capacity for Pair of Rails (Cy) - 12187 N
Load Capacity for Pair of Rails (Cz) - 4843 N
Dynamic Load for Lifetime calculation (Cdyn) - 5773 N
Weight - 16.89 kg
Description of Suffixes and Prefixes:
NTS - Full Extension telescopic rails NTS-H, with a stroke equal to 100% of the installation length
VRM - Forward and Backward Extension Including Carrier for Inner Rail
♦♦ Images are for representation purposes only
