Description
Brand - NADELLA
Item Number - NTS63-58H-1890 NADELLA
Category - Hardened Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Length (L) - 1890 mm
Extension (E) - 1946 mm
Load Capacity for Pair of Rails (Cy) - 8266 N
Load Capacity for Pair of Rails (Cz) - 2570 N
Dynamic Load for Lifetime calculation (Cdyn) - 5391 N
Weight - 36.06 kg
Description of Prefix:
NTS - Full Extension telescopic rails NTS-H, with a stroke equal to 100% of the installation length
