Description
Brand - NADELLA
Item Number - NTS43-44H-850-VRM NADELLA
Category - Hardened Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Length (L) - 850 mm
Extension (E) - 882 mm
Load Capacity for Pair of Rails (Cy) - 4751 N
Load Capacity for Pair of Rails (Cz) - 2244 N
Dynamic Load for Lifetime calculation (Cdyn) - 9732 N
Weight - 8.09 kg
Description of Suffixes and Prefixes:
NTS - Full Extension telescopic rails NTS-H, with a stroke equal to 100% of the installation length
VRM - Forward and Backward Extension Including Carrier for Inner Rail
♦♦ Images are for representation purposes only
