Description
Brand - NADELLA
Item Number - NTS43-44H-1730-VRM NADELLA
Category - Hardened Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Length (L) - 1730 mm
Extension (E) - 1742 mm
Load Capacity for Pair of Rails (Cy) - 2519 N
Load Capacity for Pair of Rails (Cz) - 1201 N
Dynamic Load for Lifetime calculation (Cdyn) - 6121 N
Weight - 16.46 kg
Description of Suffixes and Prefixes:
NTS - Full Extension telescopic rails NTS-H, with a stroke equal to 100% of the installation length
VRM - Forward and Backward Extension Including Carrier for Inner Rail
♦♦ Images are for representation purposes only
Item Number - NTS43-44H-1730-VRM NADELLA
Category - Hardened Telescopic Rails Full Extension
Principal Dimensions & Load Ratings (Metric):
Length (L) - 1730 mm
Extension (E) - 1742 mm
Load Capacity for Pair of Rails (Cy) - 2519 N
Load Capacity for Pair of Rails (Cz) - 1201 N
Dynamic Load for Lifetime calculation (Cdyn) - 6121 N
Weight - 16.46 kg
Description of Suffixes and Prefixes:
NTS - Full Extension telescopic rails NTS-H, with a stroke equal to 100% of the installation length
VRM - Forward and Backward Extension Including Carrier for Inner Rail
♦♦ Images are for representation purposes only
