Description
Brand - NADELLA
Item Number - NTS200-72-1400 NADELLA
Category - Telescopic Rails Full Extension Heavy Load
Hole Separation (C) mm - 300
Length (L) mm - 1400
Extension (E) mm - 1400
Load Capacity for Pair of Rails (Cy) N - 15000
Load Capacity for Pair of Rails (Cz) N - 7500
Maximum Load Per pair (N) - 15000
Net Weight (kg) - 129.7
