Description
Brand - NADELLA
Item Number - NTS150-56-700 NADELLA
Category - Telescopic Rails Full Extension Heavy Load
Hole Separation (B) mm - 100
Length (L) mm - 700
Extension (E) mm - 700
Load Capacity for Pair of Rails (Cy) N - 13900
Load Capacity for Pair of Rails (Cz) N - 6950
Maximum Load Per pair (N) - 13900
Net Weight (kg) - 38.6
