Description
Brand - NADELLA
Item Number - NTS150-56-1300 NADELLA
Category - Telescopic Rails Full Extension Heavy Load
Hole Separation (C) mm - 250
Length (L) mm - 1300
Extension (E) mm - 1300
Load Capacity for Pair of Rails (Cy) N - 11300
Load Capacity for Pair of Rails (Cz) N - 5650
Maximum Load Per pair (N) - 11300
Net Weight (kg) - 71.4
