Description
Brand - NADELLA
Item Number - NTS150-56-1100 NADELLA
Category - Telescopic Rails Full Extension Heavy Load
Hole Separation (C) mm - 150
Length (L) mm - 1100
Extension (E) mm - 1100
Load Capacity for Pair of Rails (Cy) N - 12100
Load Capacity for Pair of Rails (Cz) N - 6050
Maximum Load Per pair (N) - 12100
Net Weight (kg) - 60.4
