Description
Brand - NADELLA
Item Number - NTS120-44-750 NADELLA
Category - Telescopic Rails Full Extension Heavy Load
Hole Separation (B) mm - 150
Length (L) mm - 750
Extension (E) mm - 750
Load Capacity for Pair of Rails (Cy) N - 11800
Load Capacity for Pair of Rails (Cz) N - 5900
Maximum Load Per pair (N) - 11800
Net Weight (kg) - 25
