Description
Brand - NADELLA
Item Number - NTS120-44-2200 NADELLA
Category - Telescopic Rails Full Extension Heavy Load
Hole Separation (C) mm - 700
Length (L) mm - 2200
Extension (E) mm - 2200
Load Capacity for Pair of Rails (Cy) N - 3350
Load Capacity for Pair of Rails (Cz) N - 1675
Maximum Load Per pair (N) - 3900
Net Weight (kg) - 73.7
