Description
Brand - NADELLA
Item Number - NTS100-44-1500 NADELLA
Category - Telescopic Rails Full Extension Heavy Load
Hole Separation (C) mm - 350
Length (L) mm - 1500
Extension (E) mm - 1500
Load Capacity for Pair of Rails (Cy) N - 6700
Load Capacity for Pair of Rails (Cz) N - 3350
Maximum Load Per pair (N) - 6800
Net Weight (kg) - 41.5
