Description
Brand - NADELLA
Item Number - NTS100-44-1000 NADELLA
Category - Telescopic Rails Full Extension Heavy Load
Hole Separation (B) mm - 400
Length (L) mm - 1000
Extension (E) mm - 1000
Load Capacity for Pair of Rails (Cy) N - 9500
Load Capacity for Pair of Rails (Cz) N - 4750
Maximum Load Per pair (N) - 9500
Net Weight (kg) - 27.6
