Description
Brand - NTN
Item Number - 6304LLU N/2AS NTN
Also known as - 6304LLU N
Category - Deep Groove Ball Bearings Single Row
Inner (d) MM - 20
Outer (D) MM - 52
Width (B) MM - 15
Weight (kg) - 0.143
Bore - C - Cylindrical Bore
Seal - 2RS - Rubber Seal on Two Sides
Cage Type - S - Steel or Standard Cage
External Modification - N - Snap Ring Groove in Outer Ring
Radial Internal Play - Cn Normal Internal Play
Precision - Standard Precision
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Special Treatment - No Special Treatment
