Description
Brand - NTN
Item Number - 6209LLU C2 P5 NTN
Category - Deep Groove Ball Bearings Single Row
Inner (d) MM - 45
Outer (D) MM - 85
Width (B) MM - 19
Weight (kg) - 0.405
Bore - C - Cylindrical Bore
Seal - 2RS - Rubber Seal on Two Sides
Cage Type - S - Steel or Standard Cage
External Modification - No External Modification
Radial Internal Play - C2 Internal Play (Less than Cn)
Precision - P5 Precision (Higher than P6)
Lubrication - Standard Lubrication
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Special Treatment - No Special Treatment
