Description
Brand - NADELLA
Item Number - NTA80-22-800 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (B) - 400 mm
Length (L) - 800 mm
Extension (E) - 480 mm
Load Capacity for Pair of Rails (Cy) - 4600 N
Load Capacity for Pair of Rails (Cz) - 2300 N
Net Weight - 8.3 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
Item Number - NTA80-22-800 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (B) - 400 mm
Length (L) - 800 mm
Extension (E) - 480 mm
Load Capacity for Pair of Rails (Cy) - 4600 N
Load Capacity for Pair of Rails (Cz) - 2300 N
Net Weight - 8.3 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
