Description
Brand - NADELLA
Item Number - NTA70-21-550 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 150 mm
Length (L) - 550 mm
Extension (E) - 330 mm
Load Capacity for Pair of Rails (Cy) - 3900 N
Load Capacity for Pair of Rails (Cz) - 1950 N
Net Weight - 5 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
Item Number - NTA70-21-550 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 150 mm
Length (L) - 550 mm
Extension (E) - 330 mm
Load Capacity for Pair of Rails (Cy) - 3900 N
Load Capacity for Pair of Rails (Cz) - 1950 N
Net Weight - 5 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
