Description
Brand - NADELLA
Item Number - NTA59-17.5T-950 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (B) - 950 mm
Length (L) - 350 mm
Extension (E) - 630 mm
Load Capacity for Pair of Rails (Cy) - 1750 N
Load Capacity for Pair of Rails (Cz) - 875 N
Net Weight - 6.1 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
Item Number - NTA59-17.5T-950 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (B) - 950 mm
Length (L) - 350 mm
Extension (E) - 630 mm
Load Capacity for Pair of Rails (Cy) - 1750 N
Load Capacity for Pair of Rails (Cz) - 875 N
Net Weight - 6.1 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
