Description
Brand - NADELLA
Item Number - NTA150-35-1400 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 300 mm
Length (L) - 1400 mm
Extension (E) - 840 mm
Load Capacity for Pair of Rails (Cy) - 11700 N
Load Capacity for Pair of Rails (Cz) - 5850 N
Net Weight - 48.4 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
Item Number - NTA150-35-1400 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 300 mm
Length (L) - 1400 mm
Extension (E) - 840 mm
Load Capacity for Pair of Rails (Cy) - 11700 N
Load Capacity for Pair of Rails (Cz) - 5850 N
Net Weight - 48.4 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
