Description
Brand - NADELLA
Item Number - NTA120-31-1800 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 500 mm
Length (L) - 1800 mm
Extension (E) - 1080 mm
Load Capacity for Pair of Rails (Cy) - 6700 N
Load Capacity for Pair of Rails (Cz) - 3350 N
Net Weight - 42.7 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
Item Number - NTA120-31-1800 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 500 mm
Length (L) - 1800 mm
Extension (E) - 1080 mm
Load Capacity for Pair of Rails (Cy) - 6700 N
Load Capacity for Pair of Rails (Cz) - 3350 N
Net Weight - 42.7 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
