Description
Brand - NADELLA
Item Number - NTA100-26-1900 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 550 mm
Length (L) - 1900 mm
Extension (E) - 1140 mm
Load Capacity for Pair of Rails (Cy) - 3900 N
Load Capacity for Pair of Rails (Cz) - 1950 N
Net Weight - 32.3 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
Item Number - NTA100-26-1900 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 550 mm
Length (L) - 1900 mm
Extension (E) - 1140 mm
Load Capacity for Pair of Rails (Cy) - 3900 N
Load Capacity for Pair of Rails (Cz) - 1950 N
Net Weight - 32.3 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
