Description
Brand - NADELLA
Item Number - NTA100-26-1300 NADELLA
Category - Telescopic Rails Partial Extension
Principal Dimensions & Load Ratings (Metric):
Hole Separation (c) - 250 mm
Length (L) - 1300 mm
Extension (E) - 780 mm
Load Capacity for Pair of Rails (Cy) - 7500 N
Load Capacity for Pair of Rails (Cz) - 3750 N
Net Weight - 22.1 kg
Description of Prefix:
NTA - Telescopic rails partial extension
♦♦ Images are for representation purposes only
