Description
Brand - NSK
Item Number - 689ZZ1 M C3E/PS2S NSK
Category - Deep Groove Ball Bearings Single Row
Inner (d) MM - 9
Outer (D) MM - 17
Width (B) MM - 5
Inner (d) Inch - 0.3543
Outer (D) Inch - 0.6693
Width (B) Inch - 0.1969
Weight (kg) - 0.004
Bore - C - Cylindrical Bore
Seal - 2Z1
Cage Type - S - Steel or Standard Cage
External Modification - No External Modification
Radial Internal Play - Special Internal Clearance
Precision - Standard Precision
Lubrication - Low Temperature Grease
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Special Treatment - No Special Treatment
