Description
Brand - NSK
Item Number - 6224DDUC3E/ENSS NSK
Also known as - 6224 2RS C3 6224 2RS C3 G26 6224-2RS1/C3 6224-2RS1/C3QE6 6224-2RS1/C3QE6WT 6224-2RS1/C3WT 6224-2RSH-C3 6224-2RSH-C3-L100 6224-2RSR-C3 6224-2RSR-C3-L100 6224DDUC3 6224DDUC3E
Category - Deep Groove Ball Bearings Single Row
Inner (d) MM - 120
Outer (D) MM - 215
Width (B) MM - 40
Inner (d) Inch - 4.7244
Outer (D) Inch - 8.4646
Width (B) Inch - 1.5748
Weight (kg) - 5.15
Bore - C - Cylindrical Bore
Seal - 2RS - Rubber Seal on Two Sides
Cage Type - S - Steel or Standard Cage
External Modification - No External Modification
Radial Internal Play - C3 Internal Play (Higher than Cn)
Precision - Standard Precision
Lubrication - Higher and Lower Temperature Grease
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
Special Treatment - No Special Treatment
