NNU4968-S-K-M-SP FAG


Country Of Origin: Imported
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - FAG
Item Number - NNU4968-S-K-M-SP FAG
Category - Super Precision Cylindrical Roller Bearing Double Row
Inner Diameter (d) mm - 340
Outer Diameter (D) mm - 460
Width (B) mm - 118
Weight (m) kg - 54.5
Minimum Chamfer Dimension (r1 min) mm - 3
Raceway Diameter Inner Ring (F) mm - 379
Width of Lubricating Groove (ns) mm - 17.7
Diameter Lubrication Hole (ds) mm - 9.5
Axial Displacement (s) mm - 6.3
Diameter of Housing Shoulder Tolerance - H12
Diameter of Housing Shoulder (da) mm - 376
Diameter Shaft Shoulder Tolerance - h12
Diameter of Shaft Shoulder (Da) mm - 429
Maximum Recess Radius (ra1) mm - 3
Basic Dynamic Radial Load Rating (Cr) N - 1100000
Basic Static Radial Load Rating (C0r) N - 2650000
Limiting Speed for Grease Lubrication (nG grease) 1/min - 1500
Limiting Speed for Oil Lubrication (nG oil) 1/min - 1800
Radial Spring Rigidity (cr) N/µm - 9230

Description of Suffixes:

S - Lubrication Groove and Lubrication Holes in Outer Ring (Series NN30)
K - Lubrication Groove and Lubrication Holes in Outer Ring
M - Brass Cage, Guided by Rollers
SP - Special Precision

** Images are for representation purposes only
