NNU49/900-S-K-M-SP FAG

Brand - FAG
Item Number - NNU49/900-S-K-M-SP FAG
Category - Cylindrical Roller Bearings with Cage Double Row
Weight (Kg) - 784
Inner Diameter (d) mm - 900
Outer Diameter (D) mm - 1180
Inner Width (B) mm - 280
Minimum Chamfer Dimension (r) mm - 6
Axial Displacement (s) mm - 9.3
Raceway Diameter Inner Ring (F) mm - 986
Shoulder Diameter Outer Ring (D1) mm - 1093
Diameter Lubrication Hole (ds) mm - 12.5
Width of Lubricating Groove (ns) mm - 23.5
Minimum Diameter of Shaft Shoulder (da) mm - 923
Maximum Diameter of Housing Shoulder (Da) mm - 1157
Maximum Fillet Radius of Shaft (ra) mm - 5
Basic Dynamic Load Rating (Cr) kN - 7100
Basic Static Load Rating (C0r) kN - 20400
Fatigue Limit Load Rating (Cur) kN - 1920
Limiting Speed for Grease Lubrication (nG) rpm - 560
Limiting Speed for Oil Lubrication (nG) rpm - 670
