NNU49/630-S-K-M-SP FAG

Brand - FAG
Item Number - NNU49/630-S-K-M-SP FAG
Category - Cylindrical Roller Bearings with Cage Double Row
Weight (Kg) - 347
Inner Diameter (d) mm - 630
Outer Diameter (D) mm - 850
Inner Width (B) mm - 218
Minimum Chamfer Dimension (r) mm - 6
Axial Displacement (s) mm - 6.9
Raceway Diameter Inner Ring (F) mm - 704
Shoulder Diameter Outer Ring (D1) mm - 784.5
Diameter Lubrication Hole (ds) mm - 12.5
Width of Lubricating Groove (ns) mm - 23.5
Minimum Diameter of Shaft Shoulder (da) mm - 653
Maximum Diameter of Housing Shoulder (Da) mm - 827
Maximum Fillet Radius of Shaft (ra) mm - 5
Basic Dynamic Load Rating (Cr) kN - 4150
Basic Static Load Rating (C0r) kN - 11400
Fatigue Limit Load Rating (Cur) kN - 940
Limiting Speed for Grease Lubrication (nG) rpm - 800
Limiting Speed for Oil Lubrication (nG) rpm - 950
