NNU49/1180-S-K-M-SP FAG

Brand - FAG
Item Number - NNU49/1180-S-K-M-SP FAG
Category - Cylindrical Roller Bearings with Cage Double Row
Weight (Kg) - 1680
Inner Diameter (d) mm - 1180
Outer Diameter (D) mm - 1540
Inner Width (B) mm - 355
Minimum Chamfer Dimension (r) mm - 7.5
Axial Displacement (s) mm - 10
Raceway Diameter Inner Ring (F) mm - 1285
Shoulder Diameter Outer Ring (D1) mm - 1427.5
Diameter Lubrication Hole (ds) mm - 12.5
Width of Lubricating Groove (ns) mm - 23.5
Minimum Diameter of Shaft Shoulder (da) mm - 1208
Maximum Diameter of Housing Shoulder (Da) mm - 1512
Maximum Fillet Radius of Shaft (ra) mm - 6
Basic Dynamic Load Rating (Cr) kN - 12200
Basic Static Load Rating (C0r) kN - 37500
Fatigue Limit Load Rating (Cur) kN - 3200
Limiting Speed for Grease Lubrication (nG) rpm - 430
Limiting Speed for Oil Lubrication (nG) rpm - 500
