NNU49/1060-S-K-M-SP FAG

Brand - FAG
Item Number - NNU49/1060-S-K-M-SP FAG
Category - Cylindrical Roller Bearings with Cage Double Row
Weight (Kg) - 1350
Inner Diameter (d) mm - 1060
Outer Diameter (D) mm - 1400
Inner Width (B) mm - 335
Minimum Chamfer Dimension (r) mm - 7.5
Axial Displacement (s) mm - 10.5
Raceway Diameter Inner Ring (F) mm - 1160
Shoulder Diameter Outer Ring (D1) mm - 1294
Diameter Lubrication Hole (ds) mm - 12.5
Width of Lubricating Groove (ns) mm - 23.5
Minimum Diameter of Shaft Shoulder (da) mm - 1088
Maximum Diameter of Housing Shoulder (Da) mm - 1372
Maximum Fillet Radius of Shaft (ra) mm - 6
Basic Dynamic Load Rating (Cr) kN - 10400
Basic Static Load Rating (C0r) kN - 30000
Fatigue Limit Load Rating (Cur) kN - 2600
Limiting Speed for Grease Lubrication (nG) rpm - 480
Limiting Speed for Oil Lubrication (nG) rpm - 560
