NN30/1120-AS-K-M-SP FAG

Brand - FAG
Item Number - NN30/1120-AS-K-M-SP FAG
Category - Cylindrical Roller Bearings with Cage Double Row
Weight (Kg) - 2030
Inner Diameter (d) mm - 1120
Outer Diameter (D) mm - 1580
Inner Width (B) mm - 345
Minimum Chamfer Dimension (r) mm - 9.5
Axial Displacement (s) mm - 18.5
Raceway Diameter Outer Ring (E) mm - 1467
Shoulder Diameter Inner Ring (d1) mm - 1278
Diameter Lubrication Hole (ds) mm - 12.5
Width of Lubricating Groove (ns) mm - 23.5
Minimum Diameter of Shaft Shoulder (da) mm - 1154
Maximum Diameter of Housing Shoulder (Da) mm - 1546
Maximum Fillet Radius of Shaft (ra) mm - 8
Basic Dynamic Load Rating (Cr) kN - 12200
Basic Static Load Rating (C0r) kN - 30000
Fatigue Limit Load Rating (Cur) kN - 2030
Limiting Speed for Grease Lubrication (nG) rpm - 450
Limiting Speed for Oil Lubrication (nG) rpm - 530
