Description
Brand - ZEN
Item Number - NKX50-Z ZEN
Category - NKX Needle Roller Axial Bearings
Fw (mm) - 50
D (mm) - 62
D1 (mm) - 70.2
D2 (mm) - 71.5
C (mm) - 35
C1 (mm) - 14
C2 (mm) - 10
dw (mm) - 50
r (mm) - 0.6
da (mm) - 65.5
ra (mm) - 0.6
Dynamic Radial Load Rating (N) - 40850
Static Radial Load Rating (N) - 70300
Dynamic Axial Load Rating (N) - 27550
Static Axial Load Rating (N) - 71250
Limiting Speed - 3200
Weight (kg) - 0.3
Radial Play - 0.008-0.028
Outer Ring Material - AISI52100
Inner Ring Material - AISI52100
Ball Material - AISI52100
** Images are for representation purposes only
