Description
Brand - INA
Item Number - NJ2330-E-XL-MCA-C4 INA
Also known as - NJ2330-E-MCA-C4
Inner (d) MM - 150
Outer (D) MM - 320
Width (B) MM - 108
Inner (d) Inch - 5.9055
Outer (D) Inch - 12.5984
Width (B) Inch - 4.252
Weight (kg) - 44.7
Bore - C - Cylindrical Bore
Seal - No Seal
Cage Type - MA - Brass Cage, Centered on Outer Ring
External Modification - No External Modification
Radial Internal Play - C4 Internal Play (Higher than C3)
Precision - Standard Precision
Heat Stabilization - No Heat Stabilization - Temperatures up to 120 °C
** Images are for representation purposes only
