NAX 3030 IKO


Country Of Origin: JAPAN
Price:
Sale price₹ 100.00 Regular price₹ 200.00

Download data sheet

Description

Brand - IKO
Item Number - NAX 3030 IKO
Also Known As - NAX3030
Category - Needle Roller Bearings with Thrust Ball Bearing without Inner Ring
Shaft Diameter (mm) - 30
Boundary Dimension (Fw) mm - 30
Boundary Dimension (D) mm - 42
Boundary Dimension (D1) mm - 47
Boundary Dimension (D2) mm - 48
Boundary Dimension (L) mm - 30
Boundary Dimension (H) mm - 11
Boundary Dimension (l1) mm - 9.5
Minimum Boundary Dimension (rs) mm - 0.6
Boundary Dimension (di) mm - 30
Minimum Standard Mounting Dimension (da) mm - 40
Basic Radial dynamic load rating (C) N - 25100
Basic Axial dynamic load rating (C) N - 20400
Basic Radial Static load rating (C0) N - 40100
Basic Axial Static load rating (C0) N - 33600
Allowable Rotational Speed (min-1) - 6500
Weight (kg) - 0.145
Needle Roller Bearing with Dust Cover - NAX 3030Z

** Images are for representation purposes only
